Acoustic Wall Panel

Acoustic Wall Panel （ as known as Sound absorbing panel)is a functional decorative board specifically designed to improve the acoustic environment. It is made of porous/fiber materials (such as polyester fibers, mineral wool, perforated wood panels, etc.) and achieves noise reduction through the frictional loss of sound waves inside the material. Acoustic Wall Panel can effectively absorb and attenuate sound wave energy, reducing echo and noise pollution.

5 Core Characteristics of Acoustic Wall Panel
characteristic	Technical description	Application advantages
Efficient sound absorption	NRC (Noise Reduction Coefficient) 0.6-1.0, high frequency absorption better than low frequency	The conference room can reduce noise by 8-12dB
Environmental protection and safety	Formaldehyde free (HCHO ≤ 0.03mg/m ³), fire rating A (GB8624 standard)	Hospital/School Preferred
Integrated decoration	Customizable wood grain/fabric/metal finish, thickness 15-50mm	Alternative to traditional ceiling+acoustic material composite solution
Modular installation	Open frame/concealed frame keel system, supporting quick disassembly and assembly	The renovation period of old houses has been shortened by 40%
additional function	Some products integrate insulation (λ ≤ 0.035W/(m · K)) and mold prevention (ASTM G21 standard)	Suitable for humid areas in the south

Sound absorbing panels

Reduce indoor reverberation time

Suppress echoes and standing waves

Improve speech clarity (STI index)

Application scenarios

Educational Space: Classroom (with reverberation time controlled between 0.6-0.8s)

Medical building: Consultation room (privacy protection requires STI>0.6)

Commercial premises: Open plan office (background noise ≤ 45dB)

Industrial field: Factory buildings (sound insulation ≥ 25dB)

Purchase suggestions

Acoustic performance: Focus on NRC (full frequency band) and SAA (average sound absorption) values

Structural compatibility: Check the compatibility with the keel system (such as T24/U-shaped keel)

Durability: Moisture resistance (expansion rate<0.5%), deformation resistance (deflection<L/250)
